For over five decades, DORMOND Industries Limited have been producing fine quality millwork doors and paneling to architectural specifications.
Our wealth of experience has enabled limitless design possibilities for creating a unique look to your project.
Dormond Industries offers a complete range of door constructions, in an almost unlimited number of finishes, to suit your every need of Flush Wood Doors. As a made-to-order manufacturer we have the flexibility to react to customer’s specific requirements without extending lead-times and we offer value engineering and cost saving measures wherever possible. Through procurement of proprietary materials, we strive to put quality and aesthetics at the forefront of our finished products.
Additional Options are available upon request, just ask us for more details. (eg: #1 Edges; Factory Finishing; Larger Rail and/or Stile Component Sizes; Horizontal Grain & Sketch Face Veneer Doors)
To exceed industry standard, and set ourselves apart from the competition, our doors are constructed with a #2 (AWMAC Type-A) edge detail with Book-matched veneer faces c/w Flush Wood Glazing Stops for Lite cut-outs in matching, continuous lengths.
Please see our most common door constructions below.
Heavy Duty - Solid Core
(Non-Rated)
Extra Heavy Duty - Solid Core
(Non-Rated)
DCC-3 (Paint-Grade Hardboard)
This is our Extra Heavy Duty Solid Wood Door construction suitable for Paint Grade applications. Can be used for limited Exterior Grade Applications.
DCC-5 (Veneer, P.Lam or Other Surface Finish)
This is our Extra Heavy Duty Solid Wood construction for veneer, P.Lam or other surface finish applications. Can be used for limited Exterior Grade Applications.
20min & 45min
Fire-Rated Solid Core
(Agri-Fiber Wood)
DFD-3-20 (Paint-Grade Hardboard)
20min Fire-rated Solid Core Wood Door construction suitable for Paint Grade applications.
Single Swing Door Sizes up to 4/0 x 9/0; Double Door up to 8/0 x 9/0
DFD-5-20 (Veneer, P.Lam or Other Surface Finish)
20min Fire-rated Solid Core Wood Door construction suitable for veneer, P.Lam or other surface finish applications.
Single Swing Door Sizes up to 4/0 x 9/0; Double Door up to 8/0 x 9/0
DFD-3-45S (Paint-Grade Hardboard)
45min Fire-rated Agri-Fibre Wood Core Door construction suitable for Paint Grade applications.
Single Swing Door Sizes up to 4/0 x 10/0
DFD-5-45S (Veneer, P.Lam or Other Surface Finish)
45min Fire-rated Agri-Fibre Wood Core Door construction suitable for veneer, P.Lam or other surface finish applications.
Single Swing Door Sizes up to 4/0 x 10/0
DFD-3-45P (Paint-Grade Hardboard)
45min Fire-rated Uni-Cor Wood Core Door construction suitable for Paint Grade applications.
Double Door Sizes up to 8/0 x 8/0
DFD-5-45P (Veneer, P.Lam or Other Surface Finish)
45min Fire-rated Uni-Cor Wood Core Door construction suitable for veneer, P.Lam or other surface finish applications.
Double Door Sizes up to 8/0 x 8/0
60min & 90min
Fire-Rated
(Mineral Core)
DFD-3-60 (Paint-Grade Hardboard)
60min Fire-rated Mineral Core Wood Door construction suitable for Paint Grade applications.
Single Swing Door Sizes up to 4/0 x 10/0
DFD-7-60 (Veneer, P.Lam or Other Surface Finish)
60min Fire-rated Mineral Core Wood Door construction suitable for veneer, P.Lam or other surface finish applications.
Single Swing Door Sizes up to 4/0 x 10/0
DFD-3-90 (Paint-Grade Hardboard)
90min Fire-rated Mineral Core Wood Door construction suitable for Paint Grade applications.
Single Swing Door Sizes up to 4/0 x 10/0
DFD-7-90 (Veneer, P.Lam or Other Surface Finish)
90min Fire-rated Mineral Core Wood Door construction suitable for veneer, P.Lam or other surface finish applications.
Single Swing Door Sizes up to 4/0 x 10/0
Light Duty - Foam (Hollow) Core
(Non-Rated)
DHC-3 (Paint-Grade Hardboard)
Standard Lightweight Wood Door construction suitable for Paint Grade applications. With 1-1/2” SCL Stiles, it offers an approximate 40% weight savings over Solid Core Doors and is most suitable for Barn/Pocket Door applications with minimal/thru bolted hardware.
DHC-7 (Veneer, P.Lam or Other Surface Finish)
Standard Lightweight Wood Door construction suitable for Veneer, P.Lam or other surface finish applications. With 1-1/2” SCL Stiles, it offers an approximate 40% weight savings over Solid Core Doors and is most suitable for Barn/Pocket Door applications with minimal/thru bolted hardware hardware.
LITE10-3 (Paint-Grade Hardboard)
An optional Lightweight Wood Door construction for Paint Grade applications. With 3” SCL Stiles, it offers an approximate 35% weight savings over Solid Core Doors and is most suitable for Swing Door applications to accept mortise & cylindrical lockset hardware.
LITE10-7 (Veneer, P.Lam or Other Surface Finish)
An optional Lightweight Wood Door construction for Veneer, P.Lam or other surface finish applications. With 3” SCL Stiles, it offers an approximate 35% weight savings over Solid Core Doors and is most suitable for Swing Door applications to accept mortise & cylindrical lockset hardware.
LITE20-3 (Paint-Grade Hardboard)
Another optional Lightweight Wood Door construction for Paint Grade applications. It offers an approximate 30% weight savings over Solid Core Doors and is most suitable for Commercial Sliding Door applications, it features larger 4-1/2” SCL Stiles to accept larger edge machined hardware as well as larger backset surface mounted (bar pull) hardware. Softwood top & bottom caps can be easily added to these doors to increase humidity resistance.
LITE20-7 (Veneer, P.Lam or Other Surface Finish)
Another optional Lightweight Wood Door construction for Veneer, P.Lam or other surface finish applications. It offers an approximate 30% weight savings over Solid Core Doors and is most suitable for Commercial Sliding Door applications, it features larger 4-1/2” SCL Stiles to accept larger edge machined hardware as well as larger backset surface mounted (bar pull) hardware. Softwood top & bottom caps can be easily added to these doors to increase humidity resistance.
Lead - Lined - Solid Core
DPC-5-L Single Layer Lead (Paint-Grade Hardboard)
This is our standard Single Layer Lead-Lined Door construction suitable for Paint Grade applications.
DPC-7-L Single Layer Lead (Veneer, P.Lam or Other Surface Finish)
This is our standard Single Layer Lead-Lined Door construction for veneer, P.Lam or other surface finish applications.
DPC-5-LL Dual Layer Lead (Paint-Grade Hardboard)
This is our standard Dual Layer Lead-Lined Door construction suitable for Paint Grade applications.
DPC-7-LL Single Layer Lead (Veneer, P.Lam or Other Surface Finish)
This is our standard Dual Layer Lead-Lined Door construction for veneer, P.Lam or other surface finish applications.
Glazing Stop/
Lite Kit Details
Flush Wood Stops (Standard; unless otherwise specified)
This is our standard Wood Glazing Stop for 6mm Glass provided in species to match door face. Can be customized to accept a range of Glazing Thicknesses.
Overlap Wood Stops (Alternate; available upon request)
This is our alternate Wood Glazing Stop for 6mm Glass provided in species to match door face. Can be customized to accept a range of Glazing Thicknesses
Metal Vision Kit 110 (Required for 45, 60 & 90min rated doors)
This is our Metal Vision Kit required for lite cut-outs in 45, 60 & 90 minute fire-rated doors
Metal Vision Kit 115-L3 (Required for Lead-Lined doors)
This is our Metal Vision Kit required for lite cut-outs in Dual Lead-Lined doors
Dormond Basic Order Sheet
About Us
Our strength is our people. Our depth of knowledge and experience covers all facets of door production starting from veneer selection and matching, to final machining for specified hardware.
